SRM STUD & NUT WELDING

THE TECHNOLOGY OF THE FUTURE

The patented SRM stud welding process (patent no.: 10 2004 051 389), in conjunction with the innovative HZ-1 universal weld stud featuring a plane end face and centering tip (patent no.: 10 2006 016 553) enables the safe and clean welding of weld studs up to M16 at a sheet thickness to stud diameter ratio of 1:10 instead of 1:4 as previously. In this process, the use of ceramic rings is no longer needed. Application of shielding gas instead of conventional ceramic ferrules protects the welding point from the atmosphere. Material: steel, stainless steel, heat-resistant steel and aluminium. For the first time it is optionally possible to weld nuts of the commercial type M5 – M12 on punched and non-punched sheet metals requiring only special stud holders for the hexagon nuts. The numerous advantages delivered by the SRM procedure open up whole new possibilities for application especially in automated stud welding plants and large-scale component production.
COMPART Z.Dziembowski Stud & Nut Welding - BMK-8i (www.heinz-soyer.pl, www.soyer.co) COMPART Z.Dziembowski Stud & Nut Welding - BMK-16i (www.heinz-soyer.pl, www.soyer.co)

BMK-12i

The high-tech miniature inverter weighing just 7.8 kg for perfect weld quality up to M12.

more

BMK-16i

The tried and tested robust welding inverter for universal welding tasks from M3 - M16.

more

BMK-8i

The ultra-light for mobile welding up to M8 WITHOUT high-power current.

more

COMPART Z.Dziembowski Stud & Nut Welding - SRM welding guns (www.heinz-soyer.pl, www.soyer.co) COMPART Z.Dziembowski Stud & Nut Welding - BMH-22i (www.heinz-soyer.pl, www.soyer.co) COMPART Z.Dziembowski Stud & Nut Welding - HZ-1 weld fastners (www.heinz-soyer.pl, www.soyer.co)

WELDING GUNS

Here you will find an overview of our SRM welding guns.

more

WELD FASTENERS

Here you will find an overview of our HZ-1 weld fasteners. Material: Steel, Stainless steel A2-50, A5-50. New! Higher strength class 8.8

more

BMH-22i

Powerful multifunctional stud welder for automatic operation up to M22.

more
